SPECIFICATIONS

Application: River septic tank dredging, River septic tank dredging

Brand Name: NONE

Certification: CE

Charge Status: No

Condition: New

Core Components: Engine, Motor

Dimension(L*W*H): 1200*600*630

Drive Type: Crawler

Features: underwater

High-concerned chemical: none

Keywords: Sediment Dredging Robot

Machinery Test Report: Provided

Material: 304 stainless steel / carbon steel

Operating Temperature of Robot Body: -30°C to 70°C

Origin: Mainland China

Power(W): 30kw

Product name: Remote Controlled Dredging Robot

Production Capacity: 2000

Slurry pump: 3 inch/4 inch

Slurry pump flow rate: 80-100m³

Transport distance: 500m

Video outgoing-inspection: Provided

Voltage: 380V, 380V

Warranty: 1YEAR

Weight (KG): 300



PLEASE NOTE:

1.The price only for reference, the specific cost based on your requirements and

the destination port, please contact us for more product details and quotations

2.We ship you by sea !!!

3.Door to door please leave message for price !!!

4.For specific information, please consult us. Wishing you a happy life!

5.Whatsapp:+86 182 0366 6368

Emali:chunhuali681@gmail.com

CONTACT US:





Highlights at a glance

Small-sized pipeline dredging robot: Special for narrow pipelines, suitable for small-diameter municipal sewer and industrial pipeline desilting

50m depth underwater dredging robot: Standard deep-water model, applicable for reservoir, river, lake and fish pond deep silt removal

Heavy duty crawler underwater dredging robot: Industrial heavy-duty model, for coal mine, mine, chemical plant and sewage tank heavy sludge cleaning

Electric & diesel dual-power dredging robot: Dual power optional, electric for environmental protection and low energy consumption, diesel for strong power and no power supply restriction

Amphibious remote control dredging robot: Land and water dual-use, suitable for shore sludge and shallow sea dredging work

Integrated pipeline inspection and dredging robot: Dual function of real-time inspection and synchronous desilting, exclusive for municipal engineering

High pressure dredging cleaning robot: High-pressure water flow auxiliary cleaning, thorough removal of stubborn sediment and sludge

















Product Paramenters







Simple dredging robot
Item	YG-500	YG-600
Robot body	Robot size: 1250mm×500mm×450mm	Robot size: 1350mm×600mm×600mm
		Drainage width: 500mm	Drainage width: 600mm
		Travel speed: 3-9M/min	Travel speed: 3-17M/min
3.5 inch underwater special slurry pump	Used for underwater pumping of sludge
		Pumpable particle diameter: 20mm (can be changed according to customer needs)	Pumpable particle diameter: 40mm (can be changed according to customer needs)
		Lift: 15 meters (horizontal conveying distance 100-150 meters)	Lift: 30 meters (horizontal conveying distance 100-150 meters)
Special hydraulic power source for water	Hydraulic system (placed in the main control cabinet)
Robot main control compartment (control box)	Used to control all actions of the robot, including the start and stop of the robot, and the lighting system
Underwater lighting system	2 LED lights
Underwater camera system	Equipped with 1 underwater camera
Cable winding system	Electric drive (or manual), speed 0-10r/min
Underwater dedicated pipeline	50 fans
Main console	Robot ground main control system, used to control the work of underwater robots
Work efficiency	100 cubic meters per hour	150 cubic meters per hour
Suitable for pipes with a diameter greater than 0.5/0.6 meters, silt removal in rivers, and large-area rivers need to be customized according to actual conditions
